Features
l Bending operation: Traction chain structure, whole sealed waterproof
l Image display: Two image display optional
l Split machine: Main part and light source are splited
l Quality certification: ISO
l Warranty: One year(free), permanent repairs (not free)
l Package size: 64*18*48cm (G.W.:5.18kgs)
Technical Specifications
PARAMETER | SPECIFICATION |
Diameter of distal-end | Φ8.0mm |
Diameter of insert tube | Φ8.0mm |
Clamp aperture | Φ2.2mm |
Working length | 1500mm |
Total length | 1800mm |
View of field | 140° |
Depth of view | 3-100mm |
Resolution | CMOS 1,000,000 pixels |
Tip deflection | Up 180°, Down 90°, L/R 100° |
Package list
PRODUCT NAME | UNIT | QUANTITY |
Portable scope | set | 1 |
Leak detector | set | 1 |
Biopsy forceps | pc | 2 |
Cleaning brush | pc | 2 |
Attract valve anti jet cover | set | 2 |
Endoscope case | set | 1 |
USB line | set | 1 |
User manual | pc | 1 |
Certificate | pc | 1 |
Optional
PRODUCT NAME | SPECIFICATIONS | |
Laptop computer | HUAWEI MateBook D 14 SE | |
Light cold source machine | 1. Voltage: 220V-240V 2. Frequency: 50-60HZ 3.lamp Power: 15V-150W environmentally friendly halogen tungsten lamp 4. Illumination: 70000LX (using special measuring tools) 5. Color Temperature: 3000~7000K 6. Air Pump Pressure: 30-60kpa 7. Air Flow: 4L/min-10L/min (Quiet pump) | |
Trolley |
