Features
1. Manual or Automatic Bolus/Purge/KVO function.
2. Vertical & Horizontal mounting clamp.
3. DPS dynamic pressure display.
4. Anti-bolus system.
5. Large LCD display with adjustable brightness.
6. 2000 events stored can be checked/downloaded.
Technical Specifications
PARAMETER | SPECIFICATION |
Fit IV tubes | Can be used with any brand IV set after exactly calibration |
Accuracy | +/- 2% |
Delivery Rate Range | 0.1ml/h-1200ml/h (0.1ml step) |
Delivery Time Range | 00h01min~99h59min (1 min step) |
Volume Limit Range | 0.0-9999ml (1ml step) |
Total Volume Range | 0.0-9999ml (1ml step) |
Dose Mode | Volume: 0.1-999.9ml (0.1ml step) Drug Mass: 0.1-999.9ml (0.1mg step) Dose: 0.001-9999ug/kg/min (0.001ug/kg/min step) Weight: 0.1-300kg (0.1kg the least step) |
Drug Library Mode | 1030 kinds of drug names, makes drug dispensing more convenient and safer. (Optional) |
Sequential Mode | (Optional) |
KVO Rate | 0.0~5.0ml/h, Programmable and adjustable |
LOW: 60(±15) kPa, MEDIUM: 90(±15) kPa HIGH: 120(±15) kPa (Adjustable) | |
Alarms | Rate abnormal, Air in line, Door open, Empty, Occlusion, Battery Empty, No Battery, Key Holding During Infusion/Pause, Infusion Complete, No Action, Battery Low |
Alarm Volume | Three levels: LOW, MEDIUM or HIGH |
Bolus Function | Bolus rate: 1.0~1200ml/h, Bolus volume: 1.0~100ml Automatic/Manual, programmable and adjustable |
Purge Rate | Programmable and adjustable |
Interface | RS-232 |
Brightness | 1~10 levels can be selected |
History records | 2000 events stored can be checked and downloaded |
Power source | AC power supply: AC 100 to 240V( +/-10%),50/60Hz; DC Power supply: 12~15V, power>15W; Built-in Lithium Battery: Rechargeable, 11.1V, 2000mAh. 12 hours of continuous operation |
Protection Class | Class I, Type CF, IPX4 |
Dimension / N.W. | 120mm*100mm*215mm, 1.7kg |
Packing size/G.W. | 300mm*260mm*160mm, 2.5KG |
